DT-T
High frequency plastic welding machine- Design for the appointed machine
- Made in taiwan
Specifications
| Model | DT-4000T |
|---|---|
| H.F.out-put Power | 4KW |
| Oscillation Frequency | 40.68MHZ |
| Power Supply | 3Ø AC 220/380/415/440 |
| Input Power | 5KVA |
| Oscillation Tube | 日本TOSHIBA |
| Rectifier | Silicom |
| Mechanism | T type(Strengthen the mechanical tructure) |
| Method of operatio | Foot pedel |
| Control apparatus | high frequency welding timer |
| Press Stroke (mm) | 75 |
| 機械淨重(Approx) (kgs) | 360 |
| 機械毛重(Approx) (kgs) | 420 |
| 機械包裝 LxWxH(mm) | 1700*1310*1650 |
